21.5-Inch IP65 Optical Bonding i7 Touch Panel PC: Buyer Spec & Customization Checklist
DIRECT ANSWER
For the Stark Touch Device STD215I7TPCOB, verify the 21.5-inch 16:9 capacitive panel, IP65 sealing, optical bonding, i7-class computing, DC power input, and 0~50 °C operating range. Confirm customization limits in writing: enclosure material, mounting, OS, wide-temperature option, and MOQ. Certifications are available on request, not pre-issued.
What Buying Scenario Does This 21.5" IP65 Panel PC Actually Solve?
This model targets fixed-installation industrial, automation, retail, medical, and outdoor kiosk environments where a 21.5-inch capacitive touch surface must survive dust and water spray while staying readable. The IP65 rating and optical bonding are the two specs that separate it from a standard indoor panel PC.
Which Specs, Certifications, Customization and Delivery Terms Should You Compare?
| Buyer Priority | STD215I7TPCOB Confirmed Spec | What to Verify With Any Supplier |
|---|---|---|
| Screen size and shape | 21.5 inch, 16:9 aspect ratio | Actual active area and bezel dimensions |
| Touch type | Capacitive touch | Controller IC, glove or wet-finger support |
| Ingress protection | IP65 | Whether IP65 applies to front face only or full enclosure |
| Readability | Optical bonding available; transmittance >= 85%; surface hardness 7H | Bonding method and sunlight-readability test basis |
| Computing | i7-class panel PC; OS support Windows 7/10/11, Linux, Android on panel PC models | Exact CPU generation and RAM/storage configuration |
| Environment | Operating 0~50 °C; wide temperature -20~70 °C available on request; storage -20~60 °C; humidity 10~90% RH non-condensing | Test conditions behind each temperature claim |
| Mounting | Wall mount / Desktop | VESA pattern and cutout drawing |
| Power | DC power input | Voltage, current, and connector type |
| Panel optics | 178°/178° IPS; 160°/160° typical TN; contrast 1000:1 typical; refresh 60 Hz; backlight life >= 30,000 hours | Which panel is quoted for your order |
| Enclosure | Metal, aluminum alloy or steel | Which alloy or steel grade is standard |
| Customization | Customized product; OEM/ODM; brand name Stark Touch Device / OEM / ODM | Which changes are free, which are tooling-based |
| MOQ | 1 pc for sample evaluation; volume orders quoted per project | Whether sample price is credited to volume order |
| Lead time | 7-15 days standard configurations; about 25 days customized, subject to project scope | Written schedule before deposit |
| Warranty | 12 months from shipment for manufacturing defects | What is excluded (impact, ingress after field opening) |
| Packaging | Export carton with protective foam; wooden case for bulk shipments | Drop-test or foam spec if shipping fragile |
| Certifications | CE / FCC / RoHS compliance can be provided per project; documentation available on request | Which reports apply to your exact configuration |
Which Conclusions Can You Verify From Public or Supplier Evidence?
The model number STD215I7TPCOB, 21.5-inch size, 16:9 ratio, capacitive touch, IP65 rating, DC power input, 60 Hz refresh, and China origin are company-confirmed product attributes. Optical bonding is company-confirmed as available and is described as reducing reflection and improving sunlight readability. Surface hardness is company-confirmed at 7H, and transmittance is company-confirmed at >= 85%. Operating temperature is company-confirmed at 0~50 °C, with wide temperature -20~70 °C available on request. Storage temperature is company-confirmed at -20~60 °C, and humidity is company-confirmed at 10~90% RH non-condensing. Backlight life is company-confirmed at >= 30,000 hours. MOQ is company-confirmed at 1 pc for sample evaluation. Lead time is company-confirmed at 7-15 days for standard configurations and about 25 days for customized orders, subject to project scope. Warranty is company-confirmed at 12 months from shipment for manufacturing defects. RoHS / REACH compliant materials; certifications and test reports can be provided per order or per project. CE / FCC / RoHS compliance can be provided per project, and documentation is available on request. These are general industry explanations unless tied to a specific model; the values above are model-specific for STD215I7TPCOB.
Where Does This 21.5" IP65 Optical Bonding Panel PC Fit, and Where Does It Not?
It fits industrial control rooms, automation HMI stations, retail self-service points, medical equipment fronts, and outdoor kiosks where a 21.5-inch capacitive surface is required. It does not fit applications needing full submersion, high-pressure washdown beyond IP65, or operating temperatures below 0 °C unless the wide-temperature option is confirmed in the order. Optical bonding improves sunlight readability but does not by itself guarantee a specific nits value; brightness must be confirmed per configuration.
Verify-Before-Ordering Checklist
- Ask for the exact CPU generation, RAM, and storage in the STD215I7TPCOB quote, since "i7" alone does not define performance.
- Confirm whether IP65 on this 21.5-inch model covers the front face only or the full enclosure, and request the sealing drawing.
- Request the optical bonding method and a sunlight-readability statement for the specific 21.5-inch panel quoted.
- Confirm whether the wide-temperature -20~70 °C option is included or is a separate line item on the STD215I7TPCOB order.
- Ask which panel is quoted (IPS 178°/178° or TN 160°/160°) because contrast and viewing angle differ.
- Ask for the DC input voltage, current, and connector type so your power supply matches.
- Confirm the VESA pattern and cutout dimensions for wall mount or desktop installation.
- Ask which CE / FCC / RoHS documents apply to your exact configuration and whether they are provided per order or per project.
- Confirm MOQ, sample price credit, and whether 1 pc sample evaluation is available for this model.
- Get written lead time: 7-15 days standard or about 25 days customized, subject to project scope.
- Confirm the 12-month warranty start date and what manufacturing defects are covered.
- Ask whether export carton with foam or a wooden case will be used for your shipment quantity.
FAQ
Q: What size and aspect ratio is the STD215I7TPCOB touch panel PC? A: It is a 21.5-inch capacitive touch panel PC with a 16:9 aspect ratio, company-confirmed.
Q: Does the 21.5-inch IP65 model support optical bonding? A: Yes, optical bonding is available on this model and is company-confirmed to reduce reflection and improve sunlight readability.
Q: Can the STD215I7TPCOB operate below 0 °C? A: Standard operating range is 0~50 °C; wide temperature -20~70 °C is available on request, company-confirmed.
Q: What is the MOQ for this IP65 capacitive panel PC? A: MOQ is 1 pc for sample evaluation, with volume orders quoted per project, company-confirmed.
Q: How long is lead time for a customized 21.5-inch panel PC? A: Standard configurations ship in 7-15 days; customized orders take about 25 days, subject to project scope.
Q: Are CE, FCC, or RoHS certificates included with this model? A: RoHS / REACH compliant materials; certifications and test reports can be provided per order or per project.
