Shock resistance level of industrial control computers for vehicle-mounted scenarios

Vibration Resistance Ratings for Industrial Control Computers in Automotive Applications

Understanding Vibration Challenges in Automotive Environments

Dynamic Operating Conditions

Vehicles generate complex vibration patterns through multiple sources:

• Engine vibrations: Dominant at low frequencies (10-500Hz) during idling and acceleration

• Road-induced shocks: High-frequency impacts (500-2000Hz) from uneven surfaces and potholes

• Structural resonances: Amplified vibrations at specific frequencies determined by vehicle chassis design

A commercial truck operating on gravel roads experiences continuous 2-5G vibrations across its chassis, with peak shocks exceeding 10G during severe impacts. Industrial control computers mounted in such environments must withstand these forces without performance degradation.

Component-Specific Vulnerabilities

Different hardware elements have varying sensitivity thresholds:

• Hard disk drives: Susceptible to damage below 0.5G RMS at 5-200Hz

• Solid-state drives: Tolerant up to 5G RMS but sensitive to high-frequency shocks

• Connectors: Require vibration isolation to prevent micro-disconnections

• PCB traces: Need reinforcement to prevent cracking under repeated flexing

In electric vehicle battery management systems, vibration can cause intermittent contact between battery cells and monitoring circuits, leading to inaccurate state-of-charge calculations. This necessitates vibration-resistant connector designs and strain-relieved cabling.

Industry Standards for Vibration Resistance

MIL-STD-810G Compliance

The military standard defines rigorous testing procedures:

• Method 514.6: Covers operational and non-operational vibration requirements

• Test profiles: Include helicopter, tracked vehicle, and wheeled vehicle categories

• Duration: Typically 8 hours per axis for operational testing

Automotive suppliers often adopt the wheeled vehicle profile (Category 4) which specifies:

• Frequency range: 5-500Hz

• Acceleration levels: 0.76G RMS for operational mode

• Random vibration spectrum with defined power spectral density

IEC 60068-2-64 Standard

This international standard focuses on broadband random vibration:

• Test Fa: Simulates transportation vibration

• Test Fb: Replicates in-use vibration conditions
