10.4 Inch 1000-Nit Optical Bonded Industrial Touch Monitor (STD104TMOB): Buyer Spec & Customization Checklist
DIRECT ANSWER
For the 10.4 inch 1000-nit optical bonded industrial touch monitor (model STD104TMOB), verify six things before ordering: 1024 x 768 resolution at 4:3, 1000 nits brightness, IP65 sealed front panel, PCAP 10-point touch, DC24V power, and 0 C to 50 C operating range. Confirm optical bonding is included, not optional, and that custom IP66/IP69K, resistive touch, or enclosure changes are quoted per project.
What Buying Problem Does This 10.4 Inch Monitor Actually Solve?
Buyers sourcing the STD104TMOB are usually replacing a washed-out 10.4 inch panel on a machine, kiosk, or control cabinet where ambient light, dust, or washdown makes a standard 250-400 nit display unreadable. The 1000-nit backlight plus optical bonding targets that readability gap, while the 4:3 aspect ratio matches legacy 10.4 inch industrial footprints so existing cutouts and panel-mount hardware still fit.
Which Specifications Should You Compare Side by Side?
| Specification | STD104TMOB (confirmed) | What to compare against |
|---|---|---|
| Size / aspect ratio | 10.4 inch, 4:3 | 10.1 inch 16:10 or 12.1 inch 4:3 replacements |
| Resolution | 1024 x 768 | 1280 x 800 or 1920 x 1080 panels |
| Brightness | 1000 nits | 250-400 nit standard indoor panels |
| Optical bonding | Available (reduces reflection) | Air-gap bonded or non-bonded units |
| Touch | PCAP 10-point multi-touch; resistive optional | Resistive-only or PCAP-only suppliers |
| IP rating | IP65 sealed front panel; IP66/IP69K on request | IP54 or IP65-only enclosures |
| Operating temperature | 0 C to 50 C | -20 C to 70 C wide-temp panels |
| Power | DC24V, 20 W | 12V or AC-input monitors |
| Mounting | Panel mount, metal enclosure | VESA or open-frame designs |
| Warranty | 12 months | 12-36 month terms |
What Brightness and Bonding Numbers Should You Verify?
The STD104TMOB is rated at 1000 nits brightness (company-confirmed). Optical bonding is available on this model and reduces reflection to improve sunlight readability (company-confirmed). Transmittance is rated at >= 85% (company-confirmed). Surface hardness is 7H (company-confirmed). Contrast ratio is 1000:1 (company-confirmed). Viewing angle is 178 degrees (company-confirmed).
What Panel and Touch Specifications Are Fixed vs Customizable?
The panel type is TFT LCD with a 1024 x 768 resolution and 4:3 aspect ratio (company-confirmed). Pixel pitch is 0.206 mm and refresh rate is 60 Hz (company-confirmed). Response time is 25 ms (company-confirmed). Panel life is 50,000 hours, and backlight life is >= 30,000 hours (company-confirmed). Touch technology is projected capacitive (PCAP) 10-point multi-touch, with resistive available as an option (company-confirmed).
What Environmental and Mechanical Limits Apply?
Operating temperature is 0 C to 50 C (company-confirmed). Storage temperature is -20 to 60 C (company-confirmed). Humidity range is 10-90% RH, non-condensing (company-confirmed). The IP rating is IP65 on the sealed front panel, with IP66/IP69K available on request (company-confirmed). Overall dimensions are 253 x 200 x 35 mm, and the enclosure material is metal (company-confirmed). Installation method is panel mount (company-confirmed).
What Power, Certification, and Delivery Terms Should You Confirm?
Power input is DC24V with 20 W power consumption (company-confirmed). Country of origin is China (company-confirmed). RoHS / REACH compliant materials; certifications and test reports can be provided per order or per project. MOQ is 1 pc for sample evaluation, with volume orders quoted per project (company-confirmed). Lead time is 7-15 days for standard configurations and about 25 days for customized units, subject to project scope (company-confirmed). Packaging is export carton with protective foam, with wooden cases for bulk shipments (company-confirmed). Warranty is 12 months (company-confirmed).
Which Applications Fit the STD104TMOB, and Which Do Not?
The application environment covers industrial, automation, retail, medical, and outdoor kiosk use (company-confirmed). It fits panel-mount cabinets, legacy 4:3 machine interfaces, and indoor-to-semi-outdoor kiosks needing 1000-nit readability. It does not fit sub-zero freezer panels, full washdown food lines without the IP66/IP69K upgrade, or applications needing resolutions above 1024 x 768.
Verify-Before-Ordering Checklist
- Ask the supplier to confirm the STD104TMOB unit ships with optical bonding included, not as a separate line item, since bonding is listed as available rather than standard.
- Request the exact IP rating in writing: IP65 front panel as standard, or IP66/IP69K if your washdown or outdoor kiosk requires it.
- Confirm the 0 C to 50 C operating range matches your site; if you need sub-zero or above-50 C operation, ask for an alternative panel rather than assuming this model covers it.
- Ask whether the 10.4 inch 4:3 active area and 253 x 200 x 35 mm outline fit your existing cutout before tooling any bracket.
- Confirm touch choice: PCAP 10-point as standard or resistive optional, and whether the controller interface matches your host.
- Request RoHS / REACH documentation and any test reports per order or per project; certifications are available on request.
- Confirm DC24V input and 20 W draw against your power supply, and ask about connector type.
- Get written lead time: 7-15 days standard, about 25 days customized, and confirm MOQ of 1 pc for sample evaluation.
- Ask what the 12-month warranty covers, including backlight and touch layer.
FAQ
Q: Does the STD104TMOB 10.4 inch monitor include optical bonding as standard? A: Optical bonding is listed as available on this model, so confirm in writing that your order includes it.
Q: What IP rating does the 1000-nit STD104TMOB ship with? A: IP65 on the sealed front panel; IP66/IP69K is available on request for washdown or outdoor kiosk use.
Q: Can the 10.4 inch 4:3 panel operate below 0 C? A: No. Operating temperature is 0 C to 50 C; storage range is -20 to 60 C.
Q: Is resistive touch an option on this 1000-nit industrial monitor? A: Yes. PCAP 10-point multi-touch is standard; resistive touch is optional on request.
Q: How long is lead time for a customized STD104TMOB order? A: About 25 days for customized configurations, subject to project scope; standard units ship in 7-15 days.
Q: What is the minimum order for evaluating this 10.4 inch monitor? A: MOQ is 1 pc for sample evaluation; volume orders are quoted per project.
